Digital Receiver and Filter II DRF2 2298332U

2298332U
Used
Magnetic Resonance Imaging
GE HealthCare
GE HealthCare
GE HealthCare
N/A
Outright
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Easy to use
  • Low maintenance required
  • 64bit cPCI Interface
  • Reliable and durable

Other Buying Options


Condition: New

Product Overview

The Digital Receiver and Filter II DRF2 is used in Magnetic Resonance Imaging (MRI). The DRF2 is a configurable, multi-channel pre-reconstruction RF data processing circuit board. It’s a performance improved DRF1, which will provide processing for extended receiver bandwidth and channel count combinations. The DRF2 has interfaces for the cPCI (Compact PCI an industry standard bus) and receiver buses. The Synchronous Scan Protocol (SSP) commands are embedded within the receiver bus. The PCI (Peripheral Component Interconnect) bus is used to download software to the DSPs (Digital Signal Processors), provide configuration commands and transmit processed receiver data. The SSP commands provide fast configuration control at a rate up to once per view. A view refers to any single contiguous receiver data acquisition. The receiver data router FPGA gathers specific channel view data and delivers it to the DSPs for processing. The DSPs will scale, offset, demodulates, filter and decimate the data. This processed data is sent back to the FPGA, which then transmits it to a specified PCI address location. The receiver data router function provides interfaces for the receiver bus, the DSP serial links, the DSP utopia links, the local PCI bus, the serial EEPROM, the serial identification PROM, DSP interrupts, cPCI interrupts, the board test points and the board LEDS. The product is securely packaged inside a high quality packing box to avoid physical damage during transit. It is used in a wide range of medical equipment such as 1.5T Lx to 8 Channel HDX UPG, Signa MR/I Hispeed 1.5T Fixed and other medical diagnostic imaging equipment.

  • Additional Features

    • Dimensionally stable
    • Increased life span
    • Low environmental impact
    • Enhanced durability
    • Easily portable
    • Lightweight
    • High performance
    • It consumes less power
    • RoHS compliant
